(18)-3 File type
Sets the data file format.
GBD : Data file created using our company's original binary format.
CSV : Data file created with the text format.
The FFT display data is saved in the file in CSV format only (not be selected) from the FFT result.
* It cannot be replayed on the GL7000.
(18)-4 Save Range
Sets the range of data to be saved.
All data : Regardless of the cursor location, saves all data.
Data between the cursors
: Cuts and saves only the area between both the A and B cursors.
* The measurement points data and results of the function operation and overall peak list are saved as the
FFT data, regardless of the cursor operation.
(18)-5 Save
By pressing this button, data is saved according to the specifications.
CHAPTER 3 Measure and Set
3-131
