(5)-1 Start source
Sets the trigger conditions for starting data recording
Item select
Off If the Start/Stop button is pressed, recording starts regardless of condition settings.
Level Recording starts if the conditions are satisfied at the level set.
When selecting the level value, the conditions for each CH is set. Refer to "(12) Trigger level
Alarm Recording starts if an alarm occurs at a specified port.
Ext. Recording starts at an input signal from the external trigger terminal (REMOTE terminal).
* Trigger occurs when L (OV or shorted to GND) occurs.
Operations will become edge operations. Please input a signal over 500 μs.
Date Recording starts at a specified date and time.
Weekly Recording starts at a specified time on the date it's set to On.
<Ex.>: Set Mon, Tue. Wed, Thu, Fri to On and Sun, Sat to Off and specify the time as 9:00.
Time Recording starts when the specified time has elapsed.
(5)-2 Stop source
Sets trigger conditions for stopping data recording.
Item select
Off If the Start/Stop button is pressed, recording stops regardless of condition settings.
Level Recording stops if the conditions are satisfied at the level set.
When selecting the level value, the conditions for each CH is set. Refer to "(12) Trigger level
Alarm Recording starts if an alarm occurs at a specified port.
Ext. Recording stops at an input signal from the external trigger terminal (REMOTE terminal).
* Trigger occurs when L (OV or shorted to GND) occurs.
Operations will become edge operations. Please input a signal over 500 μs.
Date Recording stops at a specified date and time.
Weekly Recording stops at a specified time on the date it's set to On.
<Ex.>: Set Mon, Tue. Wed, Thu, Fri to On and Sun, Sat to Off and specify the time as 9:00.
Time Recording stops when the specified time has elapsed.
When using the stop trigger, set the interval between the start side and stop side to 1 ms or more. If the trigger on the stop
side occurs within 1 ms after the trigger on the start side occurs, the recording stops after 1 ms elapsed from the start side.
However when the recording destination is the built-in RAM, the recording stops within 1 ms at the point that the number
of recording points are exceeded.
(5)-3 Level settings
For details, refer to "(12) Trigger level settings" on page 3-105.
(5)-4 Logic settings
For details, refer to "(12) Trigger level settings" on page 3-105.
(5)-5 Alarm port number
If an alarm occurs at the port specified here, a start or stop trigger is established.
settings" on page 3-105.
Recording starts at 9:00 on weekdays. Recording is not started on a Saturday.
settings" on page 3-105.
Recording starts at 9:00 on weekdays. Recording is not started on a Saturday.
Description
Description
