GRAPHTEC gl7000 User Manual page 171

(12) Trigger level settings
Sets detailed settings of each channel when a trigger's start source, stop source is set to "Level Values".
The level trigger is determined for each channel by the contents set here. The results are combined and the
establishment (or lack thereof) for the whole trigger is decided (refer to the chart below).
CH n Mode
Pulse n
Mode
Logic n Mode
• Pulse and logic are changed with each module
• Combination settings for each module may be set to only one type. When the settings are changed, all modules are set to the same content.
When settings are changed, all modules are set to the same content.
<When using Voltage, Voltage/Temperature, High-speed Voltage,
High-voltage DC strain/Charge/Voltage Output module>
(12)-3 (12)-4
(12)-1 Start/Stop
(12)-2 Combination
(12)-3 Mode
(12)-4 H
L
Win in
Win out
<In case of Logic with the Logic/Pulse module>
(12)-3
Item select
(12)-1 Start/Stop
(12)-2 Combination
(12)-3 Mode
Level
Level Combination
Pattern
Comparison
(12)-1 (12)-2
(12)-3 (12)-4
Item select
Level
Upper level/ Upper limit value Numerical entry
Lower level
Numerical entry
(12)-1 (12)-2
Start, Stop
Level OR, Level AND, Edge OR, Edge AND
When channel is set to Logc : Off, H, L, Win in, Win out
When channel is set to Pulse: Off, H, L, Win in, Win out
Trigger
<In case of pulse with the Logic/Pulse module>
(12)-3
Examples of item
Start, Stop
Level OR, Level AND, Edge OR, Edge AND
Off, H, L, Win in, Win out
Numerical entry
Numerical entry
Examples of item
