(1) File name
Specifies the folder and file name of the recording destination. Refer to "(3) File operations" on page
3-28 on how to set a file.
(2) Name Type
Sets how the data file name is attached.
Auto : Files are automatically named.
<Ex.>: 20120101-123456.GB
User : Data is recorded to a user-input file name.
Serial number : A consecutive number is attached to the user-input file name to create the file name.
<Ex.>:
* If a file with the same name already exists, to avoid overwriting _CP* is attached to the end of the file
name where the * represents a number.
<Ex.>: TEST_CP1.GBD
(3) File Type
Sets the data file format.
GBD : A data file is created by our company's original binary format.
CSV : A data file is created with the text format.
* It cannot be replayed on the GL7000.
Please create a folder and save the file in it. Depending on file system limitations, and regardless of the remaining
free memory, saving to the root directory may not be possible.
By changing the sample interval, recording destination or number of measured channels (number off channels
where input is not Off), the free capacity and possible recording time displayed on the screen will change.
After checking, if the measurement time exceeds the possible recording time, please take one of the following
steps:
•
Changes the sample interval.
•
Copy the files at the recording destination to a PC and then delete them.
•
Switch the recording destination to a high free capacity memory option. (SD card, SSD, etc.)
Free Memory..... Displays the amount space available to be recorded on.
Possible recording time... Displays the possible recording time.
* The possible recording time is estimated up to maximum 2GB.
•
If the possible recording time exceeds 366 days, "Over 366 days" is displayed.
The numeric par . .... The day the file was created
* E.g. 2012-01-01, 12:34:56
GBD ....................... Data format
GBD (Binary data), CSV (Text format)
When the file name is "TEST"
First: TEST_SER1.GBD, Second: TEST_SER2.GBD, Third: TEST_SER3.GBD
CHAPTER 3 Measure and Set
3-55
