(15)-3 Pulse span settings
This is available only when the pulse is set in the Logic/Pulse module.
Sets the upper and lower limit value for the pulse waveform display span.
•
This setting is displayed when a Logic/Pulse module is connected and a pulse is set.
•
This setting is shared with the amplifier span setting.
(15)-4 Zone setting
Sets the zone of waveform display.
If a zone is set, the channel displayed in each zone is fixed and can not be changed.
(15)-5 Trace settings
Changes the display waveform to On/Off for each channel.
Trace settings do not affect recorded data.
CHAPTER 3 Measure and Set
3-117
