Installing a ZS5-4 Controller

This section contains installation procedures for the ZS5-4 controller.
Before beginning installation, see
Overviews" on page
Use the following procedures to install a ZS5-4 controller:
"Installing the Slide Rails onto a ZS5-4" on page 99
■
"Installing the Slide Rails into the Rack for a ZS5-4" on page 100
■
"Installing a ZS5-4 onto the Rack Slide Rails" on page 102
■
"Installing a ZS5-4 Cable Management Arm" on page 104
■
"Verifying Operation of ZS5-4 Slide-Rails and CMA" on page 106
■

Installing the Slide Rails onto a ZS5-4

Use the following procedure to install the slide rails onto a ZS5-4 controller.
The slide rails can be used with either 9.5-mm square or M6 round mounting hole racks.
Note -
1. Position a mounting bracket against the chassis so that the slide-rail lock is at
the front of the chassis, and the five keyed openings on the mounting bracket
are aligned with the five locating pins on the side of the chassis.
"Installation Prerequisites and Hardware
11.
Installing a ZS5-4 Controller 99
