Overview of ZS3-2 Controller

This section provides an overview of the Oracle ZFS Storage ZS3-2 controller. For installation
instructions, refer to
refer to
Manual.

ZS3-2 Physical Specifications

The ZS3-2 controller 2U chassis dimensions are as follows:
Dimension
Height
Width

ZS3-2 Electrical Specifications

The ZS3-2 controller electrical specifications are listed below. The power dissipation numbers
listed are the maximum rated power numbers for the power supply. The numbers are not a
rating of the actual power consumption of the appliance.
Connectors
Two C13 connectors, which work on 110-220v outlets
■
Input
Nominal frequencies: 50/60Hz (47 to 63 Hz range)
■
Nominal voltage range: 100 to 120/200 to 240 VAC
■
Maximum current AC RMS: 6.8 A @ 100-120 V / 3.4 A @ 200-240 V
■
AC operating range: 90-264 VAC
■
Output
3.3 VDC STBY: 3.0A
■
+12 VDC: 86.7A
■
Power Dissipation
"Installing a ZS3-2 Controller" on page
"Servicing the ZS3-2 Controller" in Oracle ZFS Storage Appliance Customer Service
Measurement
3.44 in./87.4 mm
17.52 in./445 mm
Overview of ZS3-2 Controller
137. For service instructions,
Dimension
Depth
Weight
Installation Prerequisites and Hardware Overviews
Measurement
20.25 in./514 mm
41.23 lb/18.70 kg
