Figure Legend
4 Connector B
7 Slide-rail latching bracket (used
with connector D)

Overview of 7420 Controller

This section provides an overview of the Oracle ZFS Storage 7420 controller. For installation
instructions, refer to
refer to
Service

7420 Physical Specifications

The 7420 controller 3U chassis dimensions are as follows:
Dimension
Height
Width

7420 Electrical Specifications

The following list shows the electrical specifications for the 7420 controller.
Note -
are not a rating of the actual power consumption of the appliance.
Input
Nominal frequencies: 50/60Hz
■
AC operating range: 100-127 VAC for 2 CPUs and 200-240 VAC for 2 or 4 CPUs
■
Maximum current AC RMS: 12A @ 100 VAC / 12A @ 200 VAC
■
Power Dissipation
"Installing a 7x20 Controller" on page
"Servicing the 7420 or 7320 Controller" in Oracle ZFS Storage Appliance Customer
Manual.
Measurement
13.3 cm/5.25 in
43.7 cm/17.19 in
The power dissipation numbers listed are the maximum rated for the power supply and
5 Connector C
8 Rear slide bar
Dimension
Depth
Weight
Installation Prerequisites and Hardware Overviews
Overview of 7420 Controller
6 Connector D
9 Cable covers
155. For service instructions,
Measurement
70.6 cm/27.8 in
16.36 kg/96 lbs
61
