Overview of Disk Shelves
FIGURE 18
Figure Legend
1 Locate button and indicator
4 Disk ready to be removed indicator
7 Over temperature warning
indicator
34
Oracle ZFS Storage Appliance Installation Guide • December 2016
Sun Disk Shelf Status Indicators (Front View)
2 System fault indicator
5 Disk fault indicator
8 SIM board fault indicator
3 System power indicator
6 Disk activity indicator
9 Power supply fault indicator
