Overview of ZS4-4 Controller
Figure Legend
10 DB-15 video port
13 Solid state drive 2 (optional)
16 Solid state drive 5 (optional)
The ZS4-4 controller has two 2.5-inch SAS-2 system boot drives in slots 0 and 1, configured
as a mirrored pair. Up to four SAS-2 read cache SSDs can fill slots 2 through 5, in that order. A
filler panel must be installed in empty drive slots. For information about supported HDDs and
SSDs, see the
The system boot drive LEDs are shown in the following figure.
FIGURE 28
TABLE 5
Figure Legend
1 Ready to remove (blue)

ZS4-4 Rear Panel Components

The ZS4-4 rear panel is shown in the following figure. Base configuration PCIe cards are
not depicted in this illustration. For more information about PCIe cards, see
Cards" in Oracle ZFS Storage Appliance Customer Service
48 Oracle ZFS Storage Appliance Installation Guide • December 2016
11 Boot drive 0 (required)
14 Solid state drive 3 (optional)
Oracle Systems Handbook.
System Boot Drive LEDs
System Boot Drive LEDs
2 Service action required (amber)
12 Boot drive 1 (required)
15 Solid state drive 4 (optional)
3 OK/Activity (green)
"ZS4-4 PCIe I/O
Manual.
