Figure Legend
5 HDD 0
9 HDD 4
13 HDD 8
17 Drive map

7120 Rear Panel Components

The following figure and legend show the rear panel.
Optional Sun Dual Port 40Gb/sec 4x Infiniband QDR HCAdapter PCIe cards (375-3606-
Note -
01) may be located in slots 1, 2, or 3. 375-3606-01 HCA expansion cards are not supported
in the 10Gb network configurations. For more information about PCIe cards, see
Options" in Oracle ZFS Storage Appliance Customer Service
7120 Controller Rear Panel
FIGURE 43
Figure Legend
1 Power Supply Unit 1
4 PCIe 3
7 Boot HDD 1
10 Serial Management port
13 USB 2.0 ports (0, 1)
The 7120 controller has the following ports:
6 HDD 1 7 HDD 2
10 HDD 5 11 HDD 6
14 HDD 9 15 HDD 10
2 Power Supply Unit 0
5 PCIe 1
8 Boot HDD 0
11 Network Management port
14 HD15 Video port
Installation Prerequisites and Hardware Overviews
Overview of 7120 Controller
8 HDD or SSD 3
12 HDD 7
16 HDD 11
"7120 PCIe
Manual.
3 PCIe 0
6 PCIe 4
9 Rear Panel System Status LEDs
12 Gbit Ethernet ports NET 0, 1, 2, 3
