FIGURE 38
Figure Legend
1 Power supply unit 0 status LEDs
OK: green Power Supply Fail: amber
AC OK: green
4 Power supply unit 1 AC inlet
7 Cluster card slot
10 PCIe slots 5-9
13 DB-15 video connector

Overview of 7320 Controller

This section provides an overview of the Oracle ZFS Storage 7320 controller. For installation
instructions, refer to
refer to
Service
7420 Controller Rear Panel
"Installing a 7x20 Controller" on page
"Servicing the 7420 or 7320 Controller" in Oracle ZFS Storage Appliance Customer
Manual.
2 Power supply unit 0 AC inlet
5 System status LEDs Power: green
Attention: amber Locate: white
8 Network (NET) 10/100/1000 ports:
NET 0-NET 3
11 Network management (NET
MGT) 10/100 BASE-T Ethernet port
Installation Prerequisites and Hardware Overviews
Overview of 7320 Controller
3 Power supply unit 1 status LEDs
OK: green Power Supply Fail: amber
AC OK: green
6 PCIe slots 0-4
9 USB 2.0 ports
12 Serial management (SER MGT)
port
155. For service instructions,
