DE3-24C Rear Panel
FIGURE 6
Figure Legend
1 Power supply filler panel, slot 4
4 Power supply with fan module 2
7 I/O Module 0
It is especially important that power supplies and their filler panels are in the correct
Note -
slots.
2 I/O Module 1
5 Power supply filler panel, slot 2
8 Power supply with fan module 1
Installation Prerequisites and Hardware Overviews
Overview of Disk Shelves
3 I/O Module filler panel
6 I/O Module filler panel
