ZS5-2 Acoustic Noise Emissions

In compliance with the requirements defined in ISO 9296, the workplace-dependent noise level
of this product is less than 75 dBA.

ZS5-2 Configuration Options

The ZS5-2 incorporates one or two controllers and one to sixteen disk shelves. Each controller
has six PCIe Gen3 slots. Each controller includes eight 2.5'' disk slots that accommodate two
system disks. Read cache devices are installed in disk shelves; therefore, the remaining six disk
slots have permanent filler panels. The following table describes the configuration options.
CPU Memory
2x18-core, 2.3 384 GB
GHz
768 GB
Refer to http://oracle.com/zfsstorage

ZS5-2 Front Panel Components

The ZS5-2 controller drive slots and front panel components are shown in the following figure.
System Disks PCIe Slots
2x2.5'' SAS-3 Two dedicated;
four available
for the most recent component specification.
Installation Prerequisites and Hardware Overviews
Overview of ZS5-2 Controller
HBA
4-port (4x4) SAS-3 12 Gb/s
external
4-port (4x4) SAS-2 6 Gb/s
external
