Connecting Disk Shelf Cables - Oracle ZS5 SERIES Installation Manual

Connecting Disk Shelf Cables

Use the following procedure to connect the cables between storage controller(s) and disk
shelves.
Caution -
Appliance" on page
The cabling configuration for your appliance depends on the number and type of controllers and
disk shelves, as well as the number of host bus adapters (HBAs) in your system. Disk shelves
attach to other disk shelves with daisy-chained serial attached SCSI (SAS) cables. Controllers
attach to each disk shelf chain with a longer SAS cable connected via HBAs located in specified
PCIe slots of the controllers. Clustered controllers are attached via three Ethernet cables that
provide redundant communication channels: two serial links and an Ethernet link. The cabling
methodology designed for the appliance includes bottom-to-top cabling for easier growth with
optimum safety, strategic slot placement for optimum load distribution and performance, and
interface redundancy for clustered controllers, ensuring no single point of failure.
1. Locate the appropriate cabling configuration for your system in
with Cabling" in Oracle ZFS Storage Appliance Cabling
"Cabling DE3-24 Disk Shelves to 4X4 Port SAS-3 HBAs" in Oracle ZFS Storage
■
Appliance Cabling Guide
"Cabling DE2-24 Disk Shelves to 4X4 Port SAS-2 HBAs" in Oracle ZFS Storage
■
Appliance Cabling Guide
"Cabling DE2-24 Disk Shelves to 2X4 Port SAS-2 HBAs" in Oracle ZFS Storage
■
Appliance Cabling Guide
"Cabling Sun Disk Shelves" in Oracle ZFS Storage Appliance Cabling Guide
■
"Cabling Mixed DE2-24 and Sun Disk Shelves" in Oracle ZFS Storage Appliance Cabling
■
Guide
Connect cables between disk shelves and between storage controller(s) and
2.
disk shelves.
If clustered controllers, be sure to connect the cluster cables as described in
Cluster Cables" on page
Example 5 Disk Shelf Cabling Example
The following illustration shows the cable connections for two clustered Oracle ZFS Storage
ZS4-4 controllers and eight DE2-24C disk shelves. The controllers, as recommended, are
located in the middle of the cabinet.
Do not connect the power cables until instructed to do so in
177.
172.
Connecting Disk Shelf Cables
"Powering On the
"Getting Started
Guide.
"Connecting
Cabling the Appliance 175
