Installing a ZS5-2 Controller

This section contains installation procedures for the ZS5-2 controller.
Before beginning installation, see
Overviews" on page
Use the following procedures to install a ZS5-2 controller:
"Installing the Mounting Brackets and Slide Rail Assemblies for a ZS5-2" on page 109
■
"Installing a ZS5-2 onto the Rack Slide Rails" on page 115
■
"Installing a ZS5-2 Cable Management Arm" on page 116
■
"Verifying Operation of ZS5-2 Slide-Rails and CMA" on page 126
■
Installing the Mounting Brackets and Slide Rail
Assemblies for a ZS5-2
Use the following procedure to install the mounting brackets and slide rail assemblies for a
ZS5-2 controller.
Unpack the slide rails and locate the slide rail lock at the front of the assembly.
1.
2. Squeeze and hold the tabs at top and bottom of the lock (1) while you pull the
mounting bracket out to the stop.
"Installation Prerequisites and Hardware
11.
Installing a ZS5-2 Controller 109
