DE3-24P Status Indicators (Front View)
FIGURE 2
Figure Legend
1 Locate indicator
4 Power supply fault indicator
7 Drive service required indicator
2 Service required indicator
5 SAS I/O Module fault indicator
8 Ready-to-remove indicator
Installation Prerequisites and Hardware Overviews
Overview of Disk Shelves
3 OK indicator
6 Power/Activity indicator
21
