Overview of Disk Shelves
FIGURE 15
Figure Legend
1 Fault/Locate indicator
4 SAS-2 Port 1
7 For Oracle service only
The DE2-24C and DE2-24P disk shelves use the same I/O Module.
FIGURE 16
32
Oracle ZFS Storage Appliance Installation Guide • December 2016
DE2 I/O Module Indicators
2 Power/OK indicator
5 SAS-2 Port 2
8 For Oracle service only
DE2 Power Supply Indicators
3 SAS-2 Port 0
6 Host port activity indicators
