Oracle ZS5 SERIES Installation Manual page 191

You can create a management interface now, or at another time using a task in
Note -
"Configuring Management Interfaces" in Oracle ZFS Storage Appliance Administration Guide,
Release OS8.6.x.
For detailed information, see the following topics:
"Working with Network Configuration" in Oracle ZFS Storage Appliance Administration
■
Guide, Release OS8.6.x
"Network Configuration" in Oracle ZFS Storage Appliance Administration Guide, Release
■
OS8.6.x
To create a management interface now, use the following steps as an example:
a.
Click the add icon
b. In the Network Datalink dialog box, set the following minimum datalink
properties.
VNIC - Select this check box.
■
Name - Enter a name for the datalink.
■
next to Datalinks.
Configuring the Appliance for the First Time
Performing Initial Configuration (BUI)
191
