Overview of ZS3-2 Controller
Optional Cable Management Arm
The following figure identifies the components of the second-generation cable management arm
(CMA). See the CMA installation instructions.
FIGURE 35
Figure Legend
1 Connector A
60
Oracle ZFS Storage Appliance Installation Guide • December 2016
Cable Management Arm Components
2 Front slide bar
3 Velcro straps (6)
