Overview of 7320 Controller

7320 Electrical Specifications

The following list shows the electrical specifications for the 7320 controller.
Note -
power supply. The numbers are not a rating of the actual power consumption of the appliance.
Connectors
Two C13 connectors, which work on 110-220v outlets
Input
Nominal frequencies: 50/60Hz
Nominal voltage range: 100-120/200-240 VAC
Maximum current AC RMS: 9.0 amps Max
AC operating range: 90-264 VAC
Output
3.3 VDC STBY: 3.6A
+12 VDC: 62.3A
Power dissipation
Max power consumption: 873 W
Max heat output: 2977 BTU/hr
Volt-Ampere rating: 891 VA @ 240 VAC, 0.98P.F.

7320 Base Configurations

The 7320 controller base configuration options are:
Single or cluster
24GB or 96GB RAM
2x2.4GHz Quad-Core processors
One external SAS HBA
Four 10/100/1000 Ethernet ports
66
Oracle ZFS Storage Appliance Installation Guide • December 2016
The power dissipation numbers listed are the maximum rated power numbers for the
