ZS5-4 Electrical Specifications

The ZS5-4 controller has two hot-swappable rear accessible power supplies with N+N
redundancy. To understand the overall power consumption, see Oracle's online power calculator
at http://www.oracle.com/goto/powercalculators.
Parameter
Nominal input frequencies
Operating input voltage range
Rated input current
Maximum power consumption
Maximum heat output

ZS5-4 Acoustic Noise Emissions

In compliance with the requirements defined in ISO 9296, the workplace-dependent noise level
of this product is less than 75 dBA (bystander position, max. ambient).

ZS5-4 Configuration Options

The ZS5-4 incorporates one or two controllers and one to forty-eight disk shelves. Each
controller has eleven PCle Gen3 slots. Each controller includes six 2.5'' disk slots that
accommodate two system disks. Read cache devices are installed in disk shelves; therefore,
the remaining four disk slots have permanent filler panels. The following table describes the
configuration options.
CPU Memory
4x18-core, 2.6 1536 GB
GHz
The most recent component specification is located at
nas/index.html.
AC Power Supplies
50/60 Hz
200-240 VAC
10 A @ 200 to 240 VAC
200W
6824 BTU/hr
System Disks PCIe Slots
2x2.5'' SAS-3 Four dedicated;
seven available
https://www.oracle.com/storage/
Installation Prerequisites and Hardware Overviews
Overview of ZS5-4 Controller
HBA
4-port (4x4) SAS-3 12 Gb/s
external
4-port (4x4) SAS-2 6 Gb/s
external
