Overview of ZS3-4 Controller

This section provides an overview of the Oracle ZFS Storage ZS3-4 controller. For installation
instructions, refer to
instructions, refer to
Customer Service

ZS3-4 Electrical Specifications

The following list shows the electrical specifications for the ZS3-4 controller.
Note -
power supply. The numbers are not a rating of the actual power consumption of the appliance.
Input
Nominal frequencies: 50/60Hz
■
AC operating range: 200-240 VAC
■
Maximum current AC RMS: 12A @ 200 VAC
■
Power Dissipation
Max power consumption: 1800 W
■
Max heat output: 6143 BTU/hr
■
Volt-Ampere rating: 1837 VA @ 240 VAC, 0.98 P.F.
■

ZS3-4 Configuration Options

The ZS3-4 controller can be configured as a single controller or two controllers to create a high-
availability cluster configuration. The following table describes the configuration options:
CPU
4x10-core, 2.40GHz
Refer to
"Installing a ZS4-4 or ZS3-4 Controller" on page
"Servicing the ZS3-4 Controller" in Oracle ZFS Storage Appliance
Manual.
The power dissipation numbers listed are the maximum rated power numbers for the
Memory
1TB (16GB DIMMs)
http://oracle.com/zfsstorage
Readzilla Boot Drive
Four SSDs Two HDDs
for the most recent component specification.
Installation Prerequisites and Hardware Overviews
Overview of ZS3-4 Controller
127. For service
HBA
4-port (4X4) SAS-2
6Gb/s external
