3.
Insert M6 screws in the top and bottom holes of each rail plate and tighten (8
total places).
4.
Install each rail by first aligning the front pins of the rack adapter plates with
corresponding holes in the front of the rail, then adjust the rail to fit the rack and
insert the pins from the rear rack adapter plates into the corresponding holes of
the rail.
Installing a Sun Disk Shelf
Installing Disk Shelves
95
