System Boot Drive LEDs
FIGURE 31
Figure Legend
1 Ready to remove (blue)
ZS3-4 Rear Panel Components
The following graphic shows the rear panel of the ZS3-4 controller. Base configuration HBAs
are not depicted in this illustration.
For information about PCIe cards, see
Appliance Customer Service
FIGURE 32
ZS3-4 Rear Panel Components
2 Service action required (amber)
"ZS3-4 PCIe I/O Cards" in Oracle ZFS Storage
Manual.
Installation Prerequisites and Hardware Overviews
Overview of ZS3-4 Controller
3 OK/Activity (green)
53
