1.
Insert the CMA mounting bracket connector (1) into the right slide rail (2) until
the connector locks into place with an audible click.
Insert the right CMA slide-rail connector (1) into the right slide-rail assembly (2)
2.
until the connector locks into place with an audible click.
3.
Insert the left CMA slide-rail connector into the left slide-rail assembly until the
connector locks into place with an audible click.
4.
Install and route cables to the controller, as required.
Installing a ZS5-4 Cable Management Arm
Installing a ZS5-4 Controller
105
