FC 300 Design Guide

4.2. General Specifications

Mains supply (L1, L2, L3):
Supply voltage
Supply voltage
Supply voltage
Supply frequency
Max. imbalance temporary between mains phases
True Power Factor (λ)
Displacement Power Factor (cos ϕ)
Switching on input supply L1, L2, L3 (power-ups) ≤ 7.5 kW
Switching on input supply L1, L2, L3 (power-ups) ≥ 11 kW
Environment according to EN60664-1
The unit is suitable for use on a circuit capable of delivering not more than 100.000 RMS sym-
metrical Amperes, 240/500/600/ 690 V maximum.
Motor output (U, V, W):
Output voltage
Output frequency (0.25-75 kW)
Output frequency (90-560 kW)
Output frequency in Flux Mode (FC 302 only)
Switching on output
Ramp times
Torque characteristics:
Starting torque (Constant torque)
Starting torque
Overload torque (Constant torque)
Starting torque (Variable torque)
Overload torque (Variable torque)
*Percentage relates to the nominal torque.
Cable lengths and cross sections:
Max. motor cable length, screened
Max. motor cable length, unscreened
Max. cross section to motor, mains, load sharing and brake, (0.25 kW - 7.5
kW)
Max. cross section to motor, mains, load sharing and brake, (11-15 kW)
Max. cross section to motor, mains, load sharing and brake, (18.5-22 kW)
Maximum cross section to control terminals, flexible/ rigid wire without cable
end sleeves
Maximum cross section to control terminals, flexible wire with cable end sleeves 1 mm
Maximum cross section to control terminals, flexible wire with cable end
sleeves with collar
Minimum cross section to control terminals
Protection and Features:
•
•
Electronic thermal motor protection against overload.
Temperature monitoring of the heatsink ensures that the frequency converter trips if the
temperature reaches a predefined level. An overload temperature cannot be reset until
the temperature of the heatsink is below the values stated in the tables on the following
MG.33.B9.02 - VLT ® is a registered Danfoss trademark
FC 301: 380-480 V / FC 302: 380-500 V ±10%
3.0 % of rated supply voltage
overvoltage category III/pollution degree 2
FC 301: 0.2 - 1000 Hz / FC 302: 0 - 1000 Hz
maximum 160% for 60 sec.
maximum 180% up to 0.5 sec.
maximum 160% for 60 sec.
maximum 110% for 60 sec.
FC 301: 50 m / FC 301 (A1-encl.): 25 m/ FC 302: 150 m
FC 301: 75 m / FC 301 (A1-encl.): 50 m/ FC 302: 300 m
4. FC 300 Selection
200-240 V ±10%
FC 302: 525-690 V ±10%
50/60 Hz
≥ 0.9 nominal at rated load
near unity (> 0.98)
maximum 2 times/min.
maximum 1 time/min.
0 - 100% of supply voltage
0 - 800 Hz
0 - 300 Hz
Unlimited
0.01 - 3600 sec.
*
*
*
*
maximum 110% for 60 sec.
4 mm 2 / 10 AWG
2
16 mm / 6 AWG
2
35 mm / 2 AWG
1.5 mm 2 /16 AWG
2
/18 AWG
0.5 mm 2 /20 AWG
2
0.25 mm / 24 AWG
4
69
