4.7.3.5 STATus:OPERation:SWEeping register

This register contains more detailed information on the operating state of the device. The device is
either set to normal receive mode (fixed frequency) or to one of several scan modes (FSCAN, MSCAN,
DSCAN, FASTLEVCW, LIST).
The status is determined by using command SENSe:FREQuency:MODE, the CW|FIXed status being
marked by clearing bits 3 to 7 from the STATus:OPERation:SWEeping register.
Table 4-5 Bit allocation of STATus:OPERation:SWEeping register
Bit No. Meaning
Hold
0
This bit is set if an FSCAN or MSCAN was interrupted due to the fulfilment of a hold criterion.
1 Running up
This bit is set if sweeping is to be carried out in the direction of increasing frequency values or memory location
numbers.
2 Running down
This bit is set if sweeping is to be carried out in the direction of decreasing frequency values or memory location
numbers.
FSCAN active
3
This bit is set if FREQ:MODE is set to SWEep.
4 MSCAN active
This bit is set if FREQ:MODE is set to MSCan.
DSCAN active
5
This bit is set if FREQ:MODE is set to DSCan (SW option EB200DS).
6 FASTlevcw active
This bit is set if FREQ:MODE is set to FASTlevcw (SW option EB200CM).
LIST active
7
This bit is set if FREQ:MODE is set to LIST (SW option EB200CM).
