R&S EB200 Manual page 16

EB200 Manual
Item. Designation
16 Display
17 Softkeys
18 TEST
19 RCL
20 Headphone
connector
21 SAVE
22 Contrast control
23 LEV
24 ON/OFF switch
25 AFC
26 ATT
4052.2000.02
Function
The display is subdivided into the working area and the softkey area and also into
areas for direct functions, VAR pot functions, menu names, spinwheel functions
Display
and the selector (see "
Function depends on the menu status. The key lettering is provided by the field
above in the display.
Self-test is performed while the key is held down.
Recalls values from a memory location to the receiver
Connector for headphones
Saves receiver values to a particular memory location
Controls display contrast
Level display (PEAK, AVG, FAST)
Switches the internal power supply on or off
Switches the AFC function on or off
Function for connecting the 30 dB attenuation path (on, off, and auto)
3.2
" on page 5)
Operation
E-7
