ANIMAS® VIBE™ SYSTEM
C H AP TE R 10 - USI N G A D VA N CE D F EA TU R ES
5.
The Bolus Total screen is displayed and the suggested (calculated) bolus
amount from your ezCarb Bolus appears in the "Total" field. Above the "Total"
field are the three parts that are used in calculating the "Total" suggested
amount. Carb refers to the carb correction amount. BG refers to the BG
correction amount calculated from the BG CORRECT screen. IOB refers to the
Insulin on Board amount from previous bolus. In this example, the Insulin on
Board feature is not turned on.
Below the suggested "Total" amount is the bolus amount entry field where you can choose to deliver
the suggested amount or adjust the amount as needed. This field will display 0.00U, and will be
highlighted and flashing. Press the
bolus amount. Then use the
desired delivery amount displayed, press
NOTE:
• Calculated total units will be rounded to the nearest .05 units.
• If the maximum bolus limit you set in Advanced Features is less than the suggested "Total" bolus
amount on the Bolus Total screen, the bolus amount entry field will change to that limit (rather than
the suggested "Total" amount) when you press the
6.
"Go" is highlighted. Press
"Type" field to select Combo Bolus, then select "Go".
If you selected the Combo Bolus option, you will begin the steps for delivering
the ezCarb units as a Combo Bolus (see Combo Bolus in this chapter). The
bolus amount you entered on the Bolus Total screen in step 6 will appear in
the "Total" field on the first Combo Bolus screen.
7.
If you are using the Dexcom G4 PLATINUM Sensor and Transmitter
with your pump, you will be prompted on the display after the bolus is
delivered to decide if the BG value you just entered should be used to
calibrate your CGM (see Chapter 5 in Section II). Select "Yes" and press
to use this BG value for CGM calibration.
NOTE:
• This screen will appear only if you are in an active CGM session. If you
decide to use the BG value for CGM calibration, the value must be within
40 – 400 mg/dL, must be from a fingerstick BG test, and must have been
taken within the last 5 minutes.
• The pump display may time out before you have had a chance to confirm the use of the BG value for
CGM calibration. In this case, the BG value will not be used for CGM calibration.
m
WARNING: DO NOT use a BG test result from an alternative sampling site (for example, your
palm or forearm) for CGM calibration. Failure to follow these instructions can result in inaccurate
Sensor glucose readings.
P130007
41028900 RevB_OB_VIBE_US_EN_MG_R4.indd 72
button once to change the amount to match the suggested
/ buttons to adjust the amount if necessary. When you have the
.
button once.
to deliver as a Normal Bolus or scroll to the
72
Dec 2014
Bolus Total
Carb
2.26U
BG +
2.61U
IOB - -.- - U
Total =
4.85U
U
0.00
Go
Type Normal
Main Menu
Bolus Total
Carb
2.26U
BG +
2.61U
IOB
- -.- - U
Total =
4.85U
0.00U
Go
Type Normal
Main Menu
Use BG
For CGM
Calibration?
Must Be A
Fingerstick
Yes N0
