ANIMAS® VIBE™ SYSTEM
C H AP TE R 5 - US I N G B AS AL PR O GR AM F EA TU R ES
NOTE:
• If you program a segment to start at the same time as an existing segment, the previously entered
segment is replaced.
• If you program a segment to start at a time that precedes an existing segment, the new segment is
automatically inserted in the correct place. You must then scroll to the new segment, highlight the
corresponding U/Hr field and enter or change amount, if desired.
6.
When finished, scroll to "Save/Review" and press
now resumed automatically. The BASAL OPTIONS screen is displayed.
a.
Select "Review" from the BASAL OPTIONS screen to review your entries for accuracy. Your basal
segment settings are shown (5 on first screen, 5 on second screen and 2 on last screen). If you have
more than 5 segments programmed, scroll to "Next" to see second and third screens as desired.
b.
If you have edited an inactive program, select the program from the BASAL MENU. Press
"Go" from the BASAL OPTIONS screen to activate the program you have selected.
When you select "Go", the Home screen is displayed, which shows the current rate of delivery for the
program that is active. (Or you can simply wait for your pump display to time out. When you press any
button, your active basal program rate information is displayed on the Home screen.)
m
CAUTION: ALWAYS review changes in your pump settings with your HCP to make sure they
are correct. Incorrect settings can result in under delivery or over delivery of insulin.
Reviewing Basal Programs
1.
From the BASAL MENU, scroll to highlight desired program. Press
2.
Scroll to "Review" from the BASAL OPTIONS
screen. Press
displayed, 5 per screen, depending on how many of
the possible segments you have programmed. If you
have more than 5 segments programmed, scroll to
"Next" on the bottom of the first or second screen to
see the second and third screens as desired.
3.
When finished reviewing the basal segment screens, press
basal program review screens. The BASAL OPTIONS screen is displayed.
4.
Scroll to "Main Menu" and press
continues.
5.
If reviewing an inactive program and you wish to activate it, select the program you wish to activate
from the BASAL MENU screen. Press
6.
Select "Go" from the BASAL OPTIONS screen to activate the program. The Home screen is displayed
to show the current rate per hour of the program you have activated.
P130007
41028900 RevB_OB_VIBE_US_EN_MG_R4.indd 30
. Your basal segment settings are
. The MAIN MENU is displayed. The active basal program
.
. If you have edited the active program, it is
.
BASAL OPTIONS
A1-WEEKDAY
Total
13.60U
Clear
Edit
Review
Go
Main Menu
with "Options" highlighted or any
30
Dec 2014
. Select
A1-WEEKDAY
Total
13.60U
Start U/Hr
12:00A 0.025
4:00A 0.675
- - : - - - - .- - -
Options Next
A138 of A312
11/14/14 2:52 PM
