ANIMAS® VIBE™ SYSTEM
cHAPtER 8 - StAtUS FEAtURE
This feature gives you easy access to a summary of information about your pump's current
programming and performance. There are seven Status screens. The Status screen number represents
the order in which the screens can be viewed.
1.
From the MAIN MENU or from the Home screen,
scroll to "Status" and press
Status Screen 1 – Active Basal
The screen displays the following information:
• Which basal program is currently active
• The 24-hour total for the active basal program
• Units per hour currently being delivered
• Insulin currently remaining in cartridge
To move to the next STATUS screen, press
bottom of the screen.
To return to the Home screen, highlight "Home" and press
Status Screen 2 – Insulin on Board, Last Bolus
The screen displays the following information:
• Amount of insulin currently "on board" (indicated by "IOB" on the screen).
For more information on this feature, see Chapter 9 in Section I.
• Type and amount of last completed bolus
˚ N = Normal
˚ C = Combo (normal portion only)
˚ A = Audio
• Time and date of last bolus
To move to the next STATUS screen, press
To return to the Home screen, highlight "Home" and press
P130007
41028900 RevB_OB_VIBE_US_EN_MG_R4.indd 43
. Bolus
CGM
Suspnd/Resum
History
Basal
Setup
Prime/Rewind
Status
with " " highlighted at the
with " " highlighted at the bottom of the screen.
43
Dec 2014
MAIN MENU
2 : 27
Basal Rate
0.025U/Hr
Insulin: 105U
Status
Home
STATUS 1
ACTIVE BASAL
A1-WEEKDAY
24-Hr Total
0.675U/Hr
Insulin: 105U
Home
.
STATUS 2
IOB=1.70U
LAST BOLUS
N 3.30U
9:55AM
Jul 8, 2010
Home
.
8
PM
Menu
13.60U
A151 of A312
