ANIMAS® VIBE™ SYSTEM
1
Get to Know Your Animas ® Vibe
System
Your Animas ® Vibe ™ System is comprised of:
• The Animas ® Vibe ™ Insulin Pump
• The Dexcom G4 PLATINUM Transmitter
• The Dexcom G4 PLATINUM Sensor and Applicator
The Animas Vibe Insulin Pump
® ™
Contrast button/CGM shortcut
Up button
Down button
Audio bolus/ezBolus
Display
Screen
OK button
Dexcom G4 PLATINUM Transmitter
(NOT DISPOSABLE)
Dexcom G4 PLATINUM Sensor
(DISPOSABLE)
Sensor Applicator
(DISPOSABLE)
Plunger
Safety Lock
Applicator Barrel
(contains small
Needle and Sensor)
Collar
Transmitter Latch
Sensor Pod
Release Tab
NOTE: If you have problems with your Sensor session, keep your Sensor until you speak with
Customer Support.
2
Set up Transmitter ID
From the MAIN MENU:
a. Press to highlight CGM and Press .
b. Press
to highlight Setup and press .
MAIN MENU MAIN MENU CGM Menu
Bolus Bolus
BG Cal.
CGM CGM
Trend Graph
Suspnd/Resum Suspnd/Resum
History History Start/Stop
Basal Basal History
Setup Setup Setup
Prime/Rewind Prime/Rewind
Status
Status Home Home Main Menu
Every time you begin using a new Transmitter you need to set the Transmitter ID. This allows
your pump and Sensor to talk to each other. Your unique Transmitter ID number makes this
possible. Be sure to remove the Transmitter from its tray when you are ready to use it. As
soon as you remove it from the tray, it begins to use battery power. Wait 10 minutes for the
Transmitter to turn on and be ready for use.
To Set Transmitter ID
a. From the CGM Setup screen, press
to highlight Transmitter and press .
CGM Setup Transmitter Transmitter
Sounds
High Alert
Low Alert
S/N # 0 0 0 0 0 S/N #
Rise Rate 6 0 0 0 0
Fall Rate
Out of Range
Transmitter
CGM Menu CGM Setup CGM Setup
b. Press
to highlight the S/N #. The last digit will be highlighted. Use the /
move to the first digit and press to activate "Edit Mode". Use the / buttons to enter
the first digit of your 5-digit ID number (found on underside of Transmitter).
c. Press after each digit is entered and repeat until the last digit is entered.
d. CGM Setup will be highlighted. Press
to return to CGM Setup screen.
41029100 RevA_QSG_VIBE_US_EN_MG_R1.indd 2
P130007
3
™ Set Alert Sounds & Levels
(optional)
You can set your pump to notify you when your CGM readings become too high or low (High/
Low Alerts), or are rising or falling too quickly (Rise Rate/Fall Rate Alerts). You can also set
your pump to let you know when your Transmitter is not within RF range of your pump (Out
of Range Alert). Alerts can be enabled/disabled and set to default or customized levels.
Customized levels should be based on your health care professional's recommendations and
your personal preferences. Some Alerts (High/Low and Out of Range Alerts) also let you set a
"snooze" period to re-alert you after a desired amount of time.
To Set Alert Sounds
a. From the CGM Setup screen, Sounds will be
CGM Setup
highlighted. Press . Sounds
High Alert
b. Highlight any Alert type. Press Low Alert
to activate
Rise Rate
"Edit Mode". Use the / buttons to set the
Fall Rate
Out of Range
desired sound for the Alert (High - Medium - Low
Transmitter
- Vibrate options). Press . CGM Menu
c. Scroll down to CGM Setup. Press
to return to CGM Setup screen.
™ button
To Set Alert Levels
a. From the CGM Setup screen highlight any Alert type. Press
b. Press
to activate "Edit Mode".
CGM Setup High Alert High Alert
Sounds
Warn above
High Alert Warn above
mg/dL 120 mg/dL
Low Alert 120
Snooze time Snooze time
Rise Rate
0 minutes 0 minutes
Fall Rate
Out of Range Enable Enable
Yes
Transmitter Yes
CGM Menu CGM Setup CGM Setup
c. Where applicable, set the level and snooze time, and choose to enable/disable the Alert.
The default snooze time is 0 minutes (no snooze) and all Alerts are enabled.
d. Scroll down to CGM Setup. Press to return to CGM Setup screen.
4
Insert Sensor & Place Transmitter
Before starting this step, you should have a Sensor, Sensor Applicator, the Transmitter, and
alcohol wipes on hand.
To Insert the Sensor
a. Clean the placement site with alcohol. Let dry. The placement site should be on your belly,
and out of the way of waistband or other areas where rubbing can occur. It should be at
least 3 inches (7.6 centimeters) away from the insulin pump infusion site.
b. Remove adhesive backing from bottom of Sensor Pod.
c. Place Sensor horizontally, NOT vertically. Press your fingers firmly around adhesive to
secure.
d. Remove Safety Lock by pulling straight out (follow arrows in picture below). Save Safety
Lock.
e. Using your thumb and finger, it may help to pinch up on your skin at base of the Sensor Pod
(use non-dominant hand).
f. With dominant hand, place 2 fingers above collar (see picture below). Put your thumb on
plunger and push down completely. You should hear 2 "clicks".
g. Using your thumb as a base, place your 2 fingers below the
collar and pull up completely. You should hear 2 "clicks".
h. Make sure the Transmitter Latch is flush against the skin.
While still holding the Applicator Barrel, use your other
hand to squeeze the ribbed Release Tabs on sides of the
Sensor Pod. Rock the Applicator Barrel forward and lift up
buttons to
and away from your body.
To Place the Transmitter
a. Clean Transmitter with alcohol wipe. Let dry.
b. Using your thumb and finger, pinch up on your skin at the base of the Sensor Pod. Place
Transmitter in Sensor Pod (flat side down, thinner side away from Latch).
c. Use a finger to hold Transmitter in place. With your other hand, move Transmitter Latch
forward until you hear 2 "clicks".
d. To remove Transmitter Latch, hold sides of Sensor Pod with one hand and Transmitter Latch
with the other. Twist off Latch.
Transmitter Latch
CGM Warning
Sounds
High Alert H
Low Alert H
Rise Rate H
Fall Rate H
Range H
Other H
CGM Setup
5
Start Sensor Session
.
To Start the Sensor Session
a. From the CGM Menu screen, scroll down to highlight Start/Stop.
High Alert
Press .
Warn above
b. START will be highlighted. Press . Confirm CGM Warning by pressing
120 mg/dL
Snooze time
0 minutes
CGM Menu Start CGM
Enable
Yes
BG Cal. Start CGM
CGM Setup
Trend Graph sensor
Start/Stop
session
History
Setup
START
Main Menu CANCEL
c. 2-hour Startup period will begin.
Check your pump approximately 10 minutes after starting
your Sensor session to make sure your pump and Transmitter are talking (
should NOT appear on the CGM Trend screen).
d. To show progression of the Startup period, a
shaded box will appear on CGM Trend screens
and gradually diminish over the 2 hours. No
CGM data is displayed during the Startup period.
6
Calibrate
At the end of the 2-hour Startup period, calibrate your CGM by taking 2 fingerstick tests with
your BG meter. BG values must be taken within 5 minutes of each other and then immediately
entered in your pump. You will also need to calibrate daily with 1 fingerstick BG value at least
once every 12 hours. Calibration values can be entered sooner or more often than every 12
hours if desired.
To Calibrate
a. After the 2-hour Startup, you will be prompted to enter 2 separate
fingerstick BG values in your pump. Press
b. Wash hands and perform fingerstick test with your BG meter.
c. From CGM Menu, BG Cal. will be highlighted.
Press .
NOTE: 120 mg/dL is the default value that appears
the first time you calibrate. Enter your actual
fingerstick BG value for calibration.
d. Use the
/ buttons to enter the BG value.
Press .
e. CANCEL will be highlighted. Use the
f. Repeat above instructions to enter second fingerstick value.
g. A minimum of 2 calibrations are needed each day. Every 12 hours
you will be prompted to enter 1 fingerstick BG value. Follow the above
instructions for entering a BG value.
"2 CLICKS"
7
CGM Trend & Data Screens
"2 CLICKS"
CGM Trend Screens
The CGM Trend screens provide a complete picture of your glucose status. CGM Trend screens
include a graphical display of your CGM readings over a 1-3-6-12-24 hour time period, based
on your preferred screen view. CGM Trend screens also provide information to assess the
speed and direction of your glucose levels.
The CGM Data Screen provides a snapshot of your current glucose status.
Access CGM Trend and Data Screens
a. From the CGM Menu screen, press to highlight Trend Graph. Press
b. Use the / buttons to scroll through the Trend screens and then the Data screens. Press
to return to the CGM Menu screen.
c. When the pump is in sleep mode, you can access CGM Trend screens directly by pressing
the Contrast/CGM Shortcut button (
Dec 2014
CGM Trend Screen
Current CGM reading
CGM readings over
the past hour
CGM Data Screen
Current Time
Current CGM reading
Remove Transmitter Latch
Trend Arrows (on CGM Data/Trend screens) and CGM readings (on CGM Trend screens) are
*
color coded. An explanation of the Trend Arrows and the color coding appears below.
† A symbol may appear in place of your current CGM reading on CGM Data/Trend screens. Refer to
the Animas ® Vibe ™ Owner's Booklet for more information.
Trend Arrows
.
Trend arrows can be used along with trend graphs to assess which direction your glucose levels
CGM Warning
are headed and how rapidly they are changing. You should not dose insulin based on trend
Always use
Fingerstick
arrow information.
BG for
Treatment
Rapidly rising: Your CGM glucose readings are rising more than 3 mg/dL each
Decisions

and CGM
minute.
Calibration
Confirm

Rising: Your CGM glucose readings are rising 2–3 mg/dL each minute.

Slowly rising: Your CGM glucose readings are rising 1–2 mg/dL each minute.
symbol
Constant: Your CGM glucose readings are steady (not increasing/decreasing

more than 1 mg/dL each minute).

Slowly falling: Your CGM glucose readings are falling 1–2 mg/dL each minute.

Falling: Your CGM glucose readings are falling 2–3 mg/dL each minute.
Rapidly falling: Your CGM glucose readings are falling more than 3 mg/dL each

minute.
No No Rate of Change Information: The CGM cannot always calculate how fast your
arrow(s) CGM glucose readings are rising or falling.
Trend Arrows and CGM glucose readings on CGM Data/Trend screens are color coded.
See explanation below:
Red arrows
High (Glucose) Alert limit set in the pump.
Green arrows
CGM Warning
High and Low (Glucose) Alert limit set in the pump.
Blue arrows
Enter 2
to confirm Warning.
Startup BGs the Low (Glucose) Alert limit set in the pump.
Confirm
8
CGM Menu BG Calibrate
End Sensor Session
BG Cal.
Trend Graph 120
Start/Stop
mg/dL
History
Setup
CALIBRATE
Main Menu CANCEL
The Sensor automatically shuts off after 7 days. Your pump will alert you 6 hours, 2 hours and
30 minutes before this happens. A final CGM Warning screen will appear when your Sensor
session has ended.
/ buttons to scroll to CALIBRATE and press .
Press to confirm your Sensor session has ended.
You can also stop your Sensor session at any time
CGM Warning
by choosing Start/Stop from CGM Menu.
Enter BG
Confirm
To Remove the Sensor Pod and Transmitter
Loosen adhesive and peel Sensor Pod/Transmitter from body.
Place Sensor Pod/Transmitter on hard surface. Hold the
rounded edge of the Safety Lock. Insert jagged edges of
Safety Lock (from Sensor Applicator) so they "hug" the
wide end of the Transmitter in the Sensor Pod.
Press Safety Lock down until you cannot press anymore and
then pull up. The Transmitter will pop out of the Sensor Pod.
NOTE: If you did not keep the Safety Lock, you can use your
.
fingers to spread out the back tabs of the Sensor Pod. The
Transmitter will then pop out.
Keep Transmitter for next Sensor session.
).
Trend Arrow *
Current Time
†
3:06 A
135
1 hr
mg/dL Graph Time Period
400
350
300
250
High (Glucose)Alert Level
(appears when this Alert is enabled)
* 200
150
100
Low (Glucose)Alert Level
50
(appears when this Alert is enabled)
Most recent CGM reading
Trend Arrow *
12:34 PM
†
142
mg/dL
Insulin on Board (Indicated by "IOB" on
the screen)
IOB 5.54U
(amount displayed only if Insulin on Board
feature is activated on the pump)
or data points mean your most recent CGM reading was at or above the
or data points mean your most recent CGM reading was between the
or data points mean your most recent CGM reading was at or below
CGM Warning CGM Warning
Sensor
CGM Session Expired,
Expires In
CGM Session
06:00 Ended
Confirm Confirm
Safety Lock
Sensor Pod tabs Sensor Pod
tab wings
7/16/14 2:25 PM
A13 of A312
