ANIMAS® VIBE™ SYSTEM
C H AP TE R 8 - S TA TU S F EA T UR E
Status Screen 3 – Delivery Today
The screen displays the following information since midnight and up to the current time stored in
the pump:
• Insulin type
• If Temp Basal has been active
• If Suspend has been active
• Total bolus amount delivered
• Total basal amount delivered
• Total insulin delivered (excluding prime amounts)
To move to the next STATUS screen, press
To return to the Home screen, highlight "Home" and press
Status Screen 4 – Combo Bolus
The screen displays the following information:
• Most recent Combo Bolus status
˚ Active or Completed or Canceled
˚ Start date
˚ Start time
˚ End time
˚ Amount delivered (if active, shows amount delivered as of current time stored in the pump)
For more information on Combo Bolus, see Chapter 10 in Section I.
To move to the next STATUS screen, press
To return to the Home screen, highlight "Home" and press
Status Screen 5 – Temp Basal
The screen displays the following information:
• Most recent Temp Basal status
˚ Active/Inactive
˚ Start date
˚ Start time
˚ End time
˚ % adjustment
To move to the next STATUS screen, press
To return to the Home screen, highlight "Home" and press
P130007
41028900 RevB_OB_VIBE_US_EN_MG_R4.indd 44
with " " highlighted at the bottom of the screen.
.
with " " highlighted at the bottom of the screen.
.
with " " highlighted at the bottom of the screen.
.
44
Dec 2014
STATUS 3
DELIVERY TODAY
U100
Temp No
Suspend No
Bolus
9.400U
Basal
0.200U
TOTAL =
9.600U
Home
STATUS 4
COMBO BOLUS
CANCELED
Mar 23, 2010
Start
07:23AM
End
07:31AM
Delivered:
3.28/9.00U
Home
STATUS 5
TEMP BASAL
ACTIVE
Mar 23, 2010
Start
04:00PM
End
06:00PM
Change:
-50%
Home
