ANIMAS® VIBE™ SYSTEM
C H AP TE R 2 - I N TR O DU CT I ON T O Y OU R A N IM AS
Sounds
Your pump allows you to customize the volume level or use the vibrate function to notify you of
warnings and alarms and to confirm certain insulin deliveries. If you are using the Dexcom G4
PLATINUM Sensor and Transmitter with your pump, you have the option to set CGM-related alarms and
alerts in the CGM Setup menu (see Chapter 2 in Section II).
Tamper Resistant (Locked) Feature
You can use the tamper resistant feature to prevent accidental button pressing. Simply wake up your
pump and press and hold the
Press & hold both arrow buttons to unlock". This locks your pump buttons. To unlock your pump, wake
up your pump so the screen reads "(LOCKED) Press & hold both arrow buttons to unlock" and press
and hold the
Basic Display Screens
Verify Screen
When you insert a battery, this is the first screen you see after the hourglass
appears on the display. From here you should verify the settings for time,
date, language and battery type. With "Confirm" highlighted, press
confirm the settings and go to the Home screen.
If you do not confirm the settings on the VERIFY screen, you will be notified
with an alarm beep sequence on your pump. If not confirmed, the pump will
play 4 long tones/vib every 3 minutes until the screen is confirmed.
It is important to have the correct (current) date and time set in your pump. If the pump loses the
date and time setting due to the battery being removed, you will not be able to go to the Home
Screen (see below) until you edit and confirm the settings on the Verify Screen.
If you are using the Dexcom G4 PLATINUM Sensor and Transmitter with your pump and you were in
the middle of a CGM session when you inserted a battery, the Verify screen will continue to appear
for about 8 seconds after pressing
Home screen appears. See Changing the Battery in Chapter 3 in Section I for detailed instructions for
changing the battery.

Home Screen

Once you have your pump set up, the Home screen is the first screen that is
displayed when you "wake up" your pump. Press the
wake up your pump. (The Home screen shows the time of day, an approximate
battery life indicator, if you have an extended bolus or temp basal currently
active, current basal rate, and how much insulin remains in your cartridge.)
You can access the MAIN MENU from here or you can take a shortcut to the
Status screen. The battery life indicator is shaded to show approximate battery
life remaining.
P130007
41028900 RevB_OB_VIBE_US_EN_MG_R4.indd 8
and buttons at the same time until the screen reads "(LOCKED)
and buttons at the same time until the screen display wakes up.
to confirm. The CGM session will automatically resume once the
VIB E I NS U LI N P U M P
® ™
to
, or button to
8
Dec 2014
VERIFY
2:27PM
Mode 12 Hr
Month Jan
Day
7
Year
2010
ENGLISH
Battery = Lith
Confirm
2 : 27 PM
Basal Rate
0.025U/Hr
Insulin: 105U
Status Menu
