ANIMAS® VIBE™ SYSTEM

cHAPtER 2 - cGm SEttINGS

Setting your Transmitter ID
Your Sensor/Transmitter and pump communicate using RF communication. RF communication will be
activated when you enter the unique Transmitter ID into the pump and start your CGM session. This
will ensure that communication takes place only between this pump and this Transmitter. Any time
you replace the Transmitter, you will need to enter the new Transmitter ID into the pump. Similarly, if
your pump is replaced, you will need to enter the current Transmitter ID into the new pump.
CGM menu options are not available while pump is suspended. DO NOT remove the Transmitter
from the tray until you are ready to use it. While the Transmitter is in the tray, it is in sleep mode
to conserve battery power. When the Transmitter is removed from the tray for the first time, it
permanently wakes up.
1.
For the initial setup, remove the Transmitter from the tray and wait 10 minutes for the Transmitter
to turn on and be ready for use.
MAIN MENU
Bolus
CGM
Suspnd/Resum
History
Basal
Setup
Prime/Rewind
Status
CGM Menu
BG Cal.
Trend Graph
Start/Stop
History
Setup
Main Menu
CGM Setup
Sounds
High Alert
Low Alert
Rise Rate
Fall Rate
Out of Range
Transmitter
CGM Menu
P130007
41028900 RevB_OB_VIBE_US_EN_MG_R4.indd 119
2.
From the MAIN MENU, scroll to "CGM" and press
Home
3.
Scroll to "Setup" on the CGM Menu and press
Transmitter
S/N # 0 0 0 0 0
CGM Setup
.
4.
Scroll to "Transmitter" and press
Transmitter screen will be displayed and "CGM
Setup" will be highlighted.
119
Dec 2014
.
. The
