15.2 Analog electronic module 4 AI I High Feature
(6ES7144-4GF00-0AB0)
Order number
6ES7144-4GF00-0AB0
Properties
● 4 inputs for current measurement
● 2 and 4-wire transmitters can be connected
● Input ranges:
● Inputs are electrically isolated from load voltage 2L+
● Diagnostics for encoder supply short-circuit to M per module
● Diagnostics for short-circuit/wire break per channel (based on the measuring range)
● Hardware interrupt on limit violation at channel 0
● Permitted common-mode voltage 5 V AC
ET 200pro distributed I/O system
Operating Instructions, 03/2013, A5E00335544-08

15.2 Analog electronic module 4 AI I High Feature (6ES7144-4GF00-0AB0)

± 20 mA, resolution 15 bit + sign
0V to 20 mA, resolution 15 bit
4 to 20 mA, resolution 15 bit
Analog electronic modules
PP
389
