Debug support (DBG)
Table 217. JTAG debug port data registers (continued)
IR(3:0)
1011
1000
Table 218. 32-bit debug port registers addressed through the shifted value A[3:2]
Address A(3:2) value
0x0
0x4
0x8
0xC
1058/1096
Data register
Access port access register
Initiates an access port and allows access to an access port register.
– When transferring data IN:
Bits 34:3 = DATA[31:0] = 32-bit data to shift in for a write request
Bits 2:1 = A[3:2] = 2-bit address (sub-address AP registers).
Bit 0 = RnW= Read request (1) or write request (0).
– When transferring data OUT:
Bits 34:3 = DATA[31:0] = 32-bit data which is read following a read
APACC
request
[35 bits]
Bits 2:0 = ACK[2:0] = 3-bit Acknowledge:
010 = OK/FAULT
001 = WAIT
OTHER = reserved
There are many AP Registers (see AHB-AP) addressed as the
combination of:
– The shifted value A[3:2]
– The current value of the DP SELECT register
Abort register
ABORT
– Bits 31:1 = Reserved
[35 bits]
– Bit 0 = DAPABORT: write 1 to generate a DAP abort.
00
Reserved
DP CTRL/STAT register. Used to:
– Request a system or debug power-up
01
– Configure the transfer operation for AP accesses
– Control the pushed compare and pushed verify operations.
– Read some status flags (overrun, power-up acknowledges)
DP SELECT register: Used to select the current access port and the
active 4-words register window.
– Bits 31:24: APSEL: select the current AP
10
– Bits 23:8: reserved
– Bits 7:4: APBANKSEL: select the active 4-words register window on the
current AP
– Bits 3:0: reserved
DP RDBUFF register: Used to allow the debugger to get the final result
11
after a sequence of operations (without requesting new JTAG-DP
operation)
Doc ID 13902 Rev 12
Details
Description
RM0008
