Debug support (DBG)

assigned for:

(default state)

Asynchronous

1. When Serial Wire mode is used, it is released. But when JTAG is used, it is assigned to JTDO.

By default, the TRACECLKIN input clock of the TPIU is tied to GND. It is assigned to HCLK

two clock cycles after the bit TRACE_IOEN has been set.

The debugger must then program the Trace Mode by writing the PROTOCOL[1:0] bits in the

SPP_R (Selected Pin Protocol) register of the TPIU.

PROTOCOL=00: Trace Port Mode (synchronous)

PROTOCOL=01 or 10: Serial Wire (Manchester or NRZ) Mode (asynchronous mode).

Default state is 01

It then also configures the TRACE port size by writing the bits [3:0] in the CPSPS_R

(Current Sync Port Size Register) of the TPIU:

0x1 for 1 pin (default state)

0x2 for 2 pins

0x8 for 4 pins

TPUI formatter

The formatter protocol outputs data in 16-byte frames:

seven bytes of data

eight bytes of mixed-use bytes consisting of:

one byte of auxiliary bits where each bit corresponds to one of the eight mixed-use

Refer to the ARM CoreSight Architecture Specification v1.0 (ARM IHI 0029B) for further

1 bit (LSB) to indicate it is a DATA byte ('0) or an ID byte ('1).

7 bits (MSB) which can be data or change of source ID trace.

if the corresponding byte was a data, this bit gives bit0 of the data.

if the corresponding byte was an ID change, this bit indicates when that ID change

takes effect.

Doc ID 13902 Rev 12

TRACE IO pin assigned

TRACECK TRACED[0]

TRACECK TRACED[0] TRACED[1]

TRACECK TRACED[0] TRACED[1] TRACED[2] TRACED[3]

(usable as GPIO)
