▼ Install the Mounting Brackets

You can optionally mount the server to the floor using the same mounting brackets
that secured the server to the shipping pallet.
Note – You must supply your own 17-mm bolts, nuts, washers, and any other
mounting hardware required to secure the server at your location.
1. Obtain the four mounting brackets and the eight 13-mm bolts that secured the
brackets to the server.
2. Obtain eight 17-mm bolts and washers that will be used to mount the server to
floor.
Note – Select bolts that are appropriate for your location. These mounting bolts are
not included with the server.
3. Drill eight 17-mm holes in the floor for the mounting brackets.
See "Mounting Holes and Cable Routing Floor Cutout Specifications" on page 28
for the dimensions of these holes.
Caution – Be careful when moving the server near floor cutouts. If the server's
castors fall into a floor cutout, the floor and the server could be severely damaged.
4. Position the server over the holes.
5. Open the server doors.
6. At the front of the server, use a T20 Torx screwdriver to loosen the three M4
captive screws securing the kick plate to the server.
Installing the Server 91
