Maximum Cable Connections
The following table lists the maximum possible number of cable connections.
Type
SPs
EMS network cables
Power cords
PCIe expansion slots
Related Information
"Physical Domains" on page 13
■
"Mandatory Cable Connections and Network Addresses" on page 59
■
"Connecting the Front SP Cables" on page 97
■
"Connect the Power Cords" on page 126
■
"Connect the EMS Network Cables" on page 134
■
"Connect Other Data Cables" on page 135
■
Maximum Number
Four cables required.
• Two CAT5, or better, serial
cables.
• Two CAT6, or better,
network cables.
32 CAT6A, or better, network
cables maximum.
• Server can contain up to 16
EMS modules.
• Each EMS module contains
two 10-GbE ports.
Six power cords required.
Maximum number of cables
varies by configuration.
Connecting the Rear Power Cords and Data Cables
Description
These SP cables are installed
in the front of the server, and
all four SP cables are required.
At least one network cable is
required for each PDomain.
The server requires six power
cords to operate.
There are 64 low-profile PCIe
expansion slots available. The
number and type of required
cables depends on the
installed PCIe cards.
121
