System Status LEDs

The server has two LED panels containing system status indicators, one located at
the front of the server and one at the rear. This topic describes the LEDs that are
required for the server installation.
Note – For complete information about all of the server LEDs, refer to the Server
Service, front and rear LED panel LEDs and controls.
No. LED
1 Fault LED (amber)
2 System OK LED (green) Indicates the following conditions:
4 SPARC M5-32 and SPARC M6-32 Servers Installation Guide • December 2014
Description
Indicates that a service action is required. Refer to the Server Service, detecting and
managing faults, for instructions if this LED lights.
• Off – System is not running in its normal state. System power might be off. The
SPs might still be running.
• Steady on – System is powered on and is running in its normal operating state.
No service actions are required.
• Short blink every three seconds – System is running in standby mode and can
be quickly returned to full function.
• Slow blink – A normal but transitory activity is taking place. Slow blinking
might indicate that system diagnostics are running or that the system is
booting.
