Physical Dimensions - Oracle sparc M5-32 Installation Manual

Physical Dimensions

Server Dimension
Height
Width
Width without removable side panels
Depth (with doors)
Depth (with doors removed)
Depth (front door handle to rear door handle)
Maximum weight (varies by configuration)
Related Information
"Leveling Feet and Caster Dimensions" on page 26
■
"Mounting Holes and Cable Routing Floor Cutout Specifications" on page 28
■
"Shipping Container Dimensions" on page 54
■
"Access Route Guidelines" on page 55
■
24 SPARC M5-32 and SPARC M6-32 Servers Installation Guide • December 2014
English Metric
78.7 in. 2000 mm
35.6 in. 904 mm
34.5 in. 876 mm
57.1 in. 1451 mm
53.6 in. 1362 mm
58.3 in. 1482 mm
Approx. 3700 lbs Approx. 1678 kg
