3. Use a 13-mm wrench to lower each leveling foot to the floor.
Turn the wrench clockwise to lower each leveling foot. When correctly lowered,
the four leveling feet will support the full weight of the server.
4. After lowering each leveling foot, use a 19-mm wrench to secure the 19-mm
locking nut to the server.
Turn the wrench counter-clockwise to secure the locking nut.
Note – If the leveling foot begins to rotate and move upward, use a 13-mm wrench
to hold the leveling foot in place while you tighten the 19-mm locking nut.
88
SPARC M5-32 and SPARC M6-32 Servers Installation Guide • December 2014
