TRACKED V. model template

This model template is suitable for tracked vehicles.
Control function assignments and names can be changed as required.
Completed tracked vehicle models typically contain a functional building block that
combines "Throttle" and "Steering" for the two power systems.
If you are using 2 separate speed controllers, it is recommended to change the
servo assignment for Steering and Throttle to TRACK+ (page 149).
TRACK+ stands for a mixer that combines "Throttle" and "Steering". You configure
the required settings in the £ Mixer menu (page 132).
Set a small deadband value in the mixer for Steering. If "Steering" and "Throttle"
are assigned to the same stick unit, opening the throttle often involves a small
steering movement. Applying a deadband to "Steering" solves this problem.
To personalise control, 4 mixers on the control side and 6 mixers on the servo side
are provided, each with eight inputs.
Controls assignment, control function, and settings
Control function Control
Turret turn Horizontal stick axis.
Assignment by
means of controls
mode.
Gun up/down Vertical stick axis.
Assignment by
means of controls
mode.
Horizontal stick axis.
Steering
Assignment by
means of controls
mode.
Throttle
---
Weapon sel.
Gear ---
Setting
FP4
Trim
Step size
FP4
Expo
D/R
FP4
Travel
FP4
Trim
Step size
FP4
Expo
D/R
FP4
Travel
FP4
Trim
Step size
FP4
Expo
D/R
FP4
Travel
FP4
¢ Trim
Step size
Mode
Expo
Slow
Slow
Fixed value
Slow
Fixed value
Model templates
Parameter
0%
1.5%
0%
100%
100%
0%
1.5%
0%
100%
100%
0%
1.5%
0%
100%
100%
0%
1.5%
CNTR
0%
0.0s
0.0s
FP4
OFF
0.0s
FP4
OFF
