Creating and customising models
7.2.5
7.2.5.1
PROFI TX
In the following example, servos 3 and 4 are swapped so that all the main rotor
servos are in sequence.
3. Select servo 3 TAIL ROTOR.
4. Press ENTER. Use the central wheel to set MAINROTOR-R.
5. Press ENTER. Set the number of curve points to 3P.
6. Press ENTER. Select servo 4.
7. Press ENTER. Use the central wheel to set TAIL ROTOR.
8. Set the number of curve points to 2P. Only the end positions then require
setting. This always yields a straight line between the points.
9. Confirm the change by pressing ENTER.
Servo 3 and servo 4 are now swapped. All the main rotor servos are
in sequence.

Checking and adjusting the main rotor

Secure the model when you set the rotation direction, centre, and travels for the
servos to prevent danger or damage due to unexpected reactions.

Checking / changing direction of servo rotation on the main rotor

The directions of travel for the servos must be checked and changed (if required)
before centre and travel are set.
Page 195
