Logical switch, which can be assigned like a normal control; it combines up to
three switches in an AND function. The result can be combined with a 4th
switch by OR. Unused AND inputs are considered switched on. The OR input
is switched off when not in use. In addition, switching can be delayed.
Mixer
For combining control functions (e.g. elevator, aileron, etc.) in various
percentages.
In the PROFI TX, 7 freely configurable mixers with 8 inputs each for mixing
on the servo side.
Mode
Defines the assignment of the main control functions Aileron, Elevator, and
Rudder to the stick units.
Model template
Template for creating new models; thanks to model templates, new models
can be created more easily and quickly since the basic configuration is more
or less completed by selecting the template. Model templates also contain the
basic configuration for mixers, controls, servos and flight phases.
Range check
Is used to check the proper operation of the radio link. The transmitter power
is reduced to approx. 1% so that the check can be performed at a shorter
distance.
Ratchet
Ratchet system in which a mechanism assumes and holds a specific position.
Servo calibration
Servo curve
Used to define the maximum control surface travels, set the neutral position,
and configure the control surface travels of servos with the same function to
the same value. Also for trimming servos on surface pairs to synchronous
operation.
Servo reverse
Used to change the rotation direction of a servo.
Snap flap
Elevator mixer to the camber-changing flaps (flaps) and/or the ailerons.
