eHeli FBL model template

In the basic configuration, this model template is optimised for helicopters with
flybarless controller. The classic configuration can easily be restored by assigning
tail rotor mixers and main rotor mixers on the servo side.
The template is equally suited to collective pitch-controlled electric helicopters with
mechanical main rotor mixer. The "Governor" mode option is activated for Throttle.
Switch off this option if you prefer to work with throttle curves (see "Throttle
(helicopter)", page 124).
Servo assignment
Servo FBL assignment
1
Aileron
2
Elevator
3
Rudder
4
Collective
5 Throttle
6 Gyro
--------- (free)
7..16
Classic assignment with mixers
(restore to flybars)
MAINROTOR-FB
MAINROTOR-L.
TAIL ROTOR
MAINROTOR-R.
Throttle
Gyro
