Transmitter
2.3
2.3.1
PROFI TX

Mechanical operations on the transmitter

Opening and closing the case

Danger of short-circuit!
Switch off the transmitter before opening the case.
Opening the case
1. Switch off the transmitter.
2. Remove the USB and headset cables.
3. Place the transmitter upside down on a soft surface.
4. Press and hold the two fasteners on the side of the screen and gently lift
the back case cover.
5. Release the fasteners, flip up the back case cover and remove it.
Page 31
