The menus
4.4.6
4.4.7
PROFI TX

Collective (only helicopters)

The Collective control function is only available for helicopter models that are
controlled using collective pitch. The curve for the "Collective" control function is
set here.
A separate collective pitch curve with 7 curve points is provided for each flight
phase.
Refer to section 7.2.9 "Setting the collective pitch curve" on page 204 for
examples of collective pitch curves.
To assist configuration the current position of the collective pitch stick is displayed
in the graph as a vertical dotted line.
P1 to P7
7-point curve, flight phase specific:
-100% - 0% - +100% for all curve points P1 to P7
Only the collective pitch curve of the activated flight phase can be displayed. When
modifying collective pitch curves make sure that the desired flight phase is activated.

Thr.Limiter (only helicopters)

The Thr.Limiter control function is only available for helicopter models. To
ensure a safe setup of the helicopter, you can use the throttle limiter to restrict the
throttle towards full throttle.
Here, you define the time needed for the throttle limiter to run up.
Setting range: 0.0s to 6.0s
Page 131
